ASTM A213 Tube Manufacturer, Supplier & Exporter in India
Nishra Overseas is a Mumbai-based manufacturer, supplier and exporter of ASTM A213 / ASME SA213 seamless ferritic and austenitic alloy-steel tubes, built for boiler, superheater, condenser and heat-exchanger service where reliability at high temperature and pressure is non-negotiable.
We supply ASTM A213 tube to fabricators, EPC contractors, boiler OEMs, and process plants across India, and export to customers throughout the Middle East, Southeast Asia, Africa and Europe. Our stock covers the most-used austenitic and ferritic alloy grades in standard sizes, and we also produce tubes to custom lengths, U-bends and non-standard dimensions against client drawings.
Every consignment is backed by complete documentation — Mill Test Certificates as per EN 10204 3.1, chemical composition and mechanical property reports, hydrostatic and NDT reports where applicable, and third-party inspection on request — so buyers can verify quality before the material even leaves our facility.
Table of Contents
- ASTM A213 Tube Specification
- ASTM A213 Grades We Supply
- Product Forms & Manufacturing Process
- Applications of ASTM A213 Tube
- Chemical Composition
- Mechanical Properties
- Sizes & Dimensions
- Testing & Documentation
- Why Buy ASTM A213 Tube from Nishra Overseas
- Request a Quote
ASTM A213 Tube Specification
Nishra Overseas manufactures and supplies ASTM A213 / ASME SA213 tube to the following general specification. Custom requirements outside this range can be quoted on request.
| Parameter | Details |
|---|---|
| Product Name | ASTM A213 / ASME SA213 Seamless Alloy & Stainless Steel Tube |
| Governing Standard | ASTM A213 / ASME SA213 |
| Manufacturing Type | Seamless cold drawn, hot finished seamless, U-bend, coiled |
| Outer Diameter | 6.35 mm to 152 mm (1/4" to 6") |
| Wall Thickness | 0.5 mm to 12 mm |
| Length | Up to 6 meters standard; custom cut lengths on request |
| Form | Straight lengths, U-bend, coiled tube |
| Finish | Pickled & annealed, bright annealed, polished |
| End Condition | Plain end, capped end |
ASTM A213 Grades We Supply
ASTM A213 TP304 / TP304L / TP304H Tube
General-purpose austenitic stainless tube suited to moderate-temperature heat exchanger and process tubing duty, with TP304L offering lower carbon for better weldability.
ASTM A213 TP316 / TP316L / TP316H / TP316Ti Tube
Molybdenum-alloyed grades that hold up better against chlorides and aggressive process fluids than the 304 series, commonly specified for chemical and marine-adjacent environments.
ASTM A213 TP321 / TP321H Tube
Titanium-stabilized grade that resists sensitization and intergranular corrosion at elevated temperatures, often used where welded joints will see sustained heat.
ASTM A213 TP347 / TP347H Tube
Niobium-stabilized grade with strong high-temperature creep resistance, widely specified for superheater tubing in power boilers.
ASTM A213 TP310S Tube
High chromium-nickel austenitic grade offering strong oxidation resistance for the hottest zones of a boiler or furnace circuit.
ASTM A213 Ferritic Alloy Steel Tube (T5, T9, T11, T12, T22, T91)
Chromium-molybdenum alloy tubes built for high-pressure, high-temperature boiler and superheater service, offering a cost-effective alternative to austenitic grades where the application allows.
Product Forms & Manufacturing Process
Nishra Overseas supplies ASTM A213 tube in the following forms:
- Seamless straight tube
- U-bend tube
- Coiled tube
- Cold Drawn Seamless (CDS) tube
- Hot Finished Seamless (HFS) tube
Delivery Condition
Annealed & pickled, cold drawn, or bright annealed — as specified by the customer.
Applications of ASTM A213 Tube
- Water tube and fire tube boilers
- Superheaters and reheaters
- Feedwater heaters
- Condensers
- Shell & tube heat exchangers
- Refinery and fertilizer plant process piping
- Chemical and petrochemical processing equipment
Chemical Composition (%)
| Grade | C | Mn | P | S | Si | Cr | Ni | Mo |
|---|---|---|---|---|---|---|---|---|
| TP304 | 0.08 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 18.0–20.0 | 8.0–11.0 | — |
| TP304L | 0.035 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 18.0–20.0 | 8.0–13.0 | — |
| TP304H | 0.04–0.10 | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 18.0–20.0 | 8.0–11.0 | — |
| TP316 | 0.08 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 16.0–18.0 | 11.0–14.0 | 2.00–3.00 |
| TP316L | 0.035 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 16.0–18.0 | 10.0–14.0 | 2.00–3.00 |
| TP316H | 0.04–0.10 | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 16.0–18.0 | 11.0–14.0 | 2.00–3.00 |
| TP321 | 0.08 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 17.0–19.0 | 9.0–12.0 | — |
| TP347 | 0.08 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 17.0–19.0 | 9.0–13.0 | — |
| TP310S | 0.08 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 24.0–26.0 | 19.0–22.0 | — |
Mechanical Properties
| Grade | Tensile Strength (min) | Yield Strength (min) | Elongation (min) |
|---|---|---|---|
| TP304 | 75 ksi (515 MPa) | 30 ksi (205 MPa) | 35% |
| TP304L | 70 ksi (485 MPa) | 25 ksi (170 MPa) | 35% |
| TP316 | 75 ksi (515 MPa) | 30 ksi (205 MPa) | 35% |
| TP316L | 70 ksi (485 MPa) | 25 ksi (170 MPa) | 35% |
| TP321 | 75 ksi (515 MPa) | 30 ksi (205 MPa) | 35% |
| TP347 | 75 ksi (515 MPa) | 30 ksi (205 MPa) | 35% |
| TP310S | 75 ksi (515 MPa) | 30 ksi (205 MPa) | 35% |
Figures are per ASTM A213 for solution-annealed condition. Contact us for grade-specific datasheets.
Sizes & Dimensions
| Parameter | Range |
|---|---|
| Outside Diameter | 3/8" (9.5 mm) to 6" (152.4 mm) |
| Wall Thickness | 0.6 mm to 6.0 mm (custom thickness on request) |
| Standard Length | Up to 6 meters |
| Custom Lengths | Cut-to-size available on request |
Commonly ordered sizes are held in stock at our Mumbai warehouse for quick dispatch on shutdown and emergency orders.
Testing & Documentation
- Mill Test Certificate as per EN 10204 3.1
- Chemical composition report
- Mechanical property report
- Hydrostatic test report
- Non-destructive testing (NDT) report, where applicable
- Third-party inspection report on request
Why Buy ASTM A213 Tube from Nishra Overseas
Manufacturer, Supplier & Exporter
One point of contact for sourcing, quality control and worldwide delivery.
Broad Grade & Size Range
TP304 through TP347H plus ferritic alloy grades, in seamless, U-bend and coiled forms.
Mumbai Warehouse Stock
Ready stock of standard sizes for fast turnaround on domestic and shutdown orders.
Established Export Network
Regular supply to buyers across the Middle East, Southeast Asia, Africa and Europe.
Full Traceability
Every order shipped with MTC, chemical/mechanical reports, and inspection documentation.
Custom Fabrication
Cut lengths, U-bends and non-standard sizes made to client drawings.
Competitive, Direct Pricing
Direct stockholding and sourcing keep pricing competitive on both small and bulk orders.
Request a Quote for ASTM A213 Tube
Looking for a dependable ASTM A213 tube manufacturer, supplier or exporter in India? Send us your grade, size and quantity requirement and our team will respond with pricing and availability within 24 hours.
📞 Call/WhatsApp: +91-7021931392
✉️ Email: sales@nishraoverseas.com
📍 Location: Mumbai, India
