ASTM A269 Stainless Steel Tube
Get In Touch
ASME SA269 TP304 Seamless Tubing and A269 Grade TP316 Square Tube Manufacturer, Supplier & Exporter in India
Nishra Overseas LLP is a leading ASTM A269 Stainless Steel Tube Manufacturer in India, and a trusted ASTM A269 Tube Supplier in India and ASTM A269 Tube Exporter in India, serving customers across India and 50+ countries worldwide from our facility in Mumbai. As an ISO 9001:2015 certified company, we manufacture and supply ASTM A269 Stainless Steel Tube known for its high strength and reliability across demanding applications.
Stainless steel is used extensively in the manufacturing of tubes and pipes, with properties classified by grade number based on the elements added during production. ASTM A269 Stainless Steel Tube is one such grade, known for displaying high strength. ASTM A269 TP316L Stainless Steel Tubing is also engineered to resist high pressure and high temperature. As a manufacturer, our ASTM A269 TP304 Stainless Steel Seamless Tubes are made to a nominal wall thickness specification and can bear high mechanical stress. ASTM A269 TP304 tubes resist corrosion in both low and high temperatures, and are typically supplied with a thickness of ¼ inch.
ASTM A269 Stainless Steel Tubing — Manufacturer, Supplier & Exporter in India
As an ASTM A269 Tube Manufacturer in India, Nishra Overseas LLP manufactures ASTM A269 TP304 Seamless Tube using electric fusion weld, electric resistance weld, and seamless cold drawing processes. Our ASTM A269 TP304 Stainless Steel Tubing can be heat treated and is available in a range of finishes. ASTM A269 TP304L tubes we supply are suited to applications operating under high temperature and high pressure, while our ASTM A269 TP316L Tubes are equally suited to low-temperature, low-pressure applications. As an ASTM A269 Tube Supplier in India, we supply ASTM A269 Grade TP316 tubes widely to hydraulic systems, textile, marine, and chemical industries, given their high tolerance for chloride-ion-rich environments.
ASTM A269 Grade TP316L Stainless Steel Seamless Tubes supplied by Nishra Overseas LLP also resist oxidizing agents and provide good general corrosion resistance. Our ASTM A269 TP304 Square Tube is a more versatile version of the standard tube, well known for its ductility and weldability, while our ASTM A269 TP304 Rectangular Tube offers heavier wall thickness for mechanical applications. As an ASTM A269 Tube Exporter in India, we supply ASTM A269 TP304 Stainless Steel Exhaust Tube that is ideal for food, chemical, beverage, and petrochemical processing applications. ASME SA269 TP304 Stainless Steel Seamless Tubes are pocket-friendly and less expensive compared to other tube grades, and every batch of ASTM A269 TP316 Stainless Steel Seamless Tubes produced by Nishra Overseas LLP is passed through rigorous testing to confirm its properties.
Buy ASTM A269 TP304 Stainless Steel Tubing and ASME SA269 TP316L Rectangular Tube in cut-to-size lengths at no extra cost from Nishra Overseas LLP.
Table of Content
- ASTM A269 Stainless Steel Tubing Specification
- Types of ASTM A269 Stainless Steel Tubing We Manufacture, Supply & Export
- ASTM A269 Stainless Steel Tubing Price List
- ASTM A269 Stainless Steel Tubing Composition and Properties
- ASTM A269 Stainless Steel Tubing Pressure Rating
- ASTM A269 SS Tubing Dimensions
- Why Choose Nishra Overseas LLP
ASTM A269 Stainless Steel Tubing Specification
Nishra Overseas LLP supplies Mill Finish & Polished ASTM A269 TP304L Stainless Steel Tubes at factory price in Mumbai — check specification and stock sizes below.
- Product Name: ASTM A269 Stainless Steel Tubing
- Type: Seamless Cold Drawn Tubes, Hot Finished Seamless Pipes, Welded Pipes, Fabricated Pipes
- Grades: ASTM A269 TP304, TP304L, TP304H, TP321H, TP321, TP316, TP316L, TP316Ti, TP310S, TP347, TP347H
- Size: 1/8" NB to 24" NB; 1/4" OD to 24" OD sizes also available
- Length: Up to 6 meters, custom cut lengths available
- Thickness: 1mm to 20mm; SCH 5/5S, 10/10S, 20/20S, 40/40S, 80/80S, 120/120S, 160/160S as per ANSI B36.19/36.10
- Finish: No.1 Pickled Finish, No.4 Finish, BA Finish, Electropolished Seamless Pipes
- Our Network: Mumbai, Chennai, Bangalore, Gujarat, India | Malaysia, Singapore, Saudi Arabia, UAE
Types of ASTM A269 Stainless Steel Tubing We Manufacture, Supply & Export
ASTM A269 TP316L Tubing Manufacturer & Supplier
Nishra Overseas LLP is a manufacturer, supplier and exporter of ASTM A269 TP316L Tubing, also known as Alloy 304L Tubing, ASTM A269 UNS S30403 Tubing. We have the flexibility to produce and supply precision thick-wall and thin-wall A269 TP316L tubes and pipes in seamless, welded and redrawn forms.
- Available product forms: ASTM A269 TP316L Straight Tubing, ASTM A269 TP316L Seamless Tubing
- Typical manufacturing specifications: ASTM A312, ASTM A213, ASTM A249, ASTM A554, and individual customer specifications
- Form: SS 304L Round Pipes/Tubes, SS 304L Square Pipes/Tubes, SS 304L Rectangular Pipes/Tubes, SS 304L Coiled Tubes, SS 304L "U" Shape, SS 304L Cake Coils, SS 304L Hydraulic Tubes, SS 304L Large Diameter Custom Size Pipe, SS 304L Rectangle Tubes, JIS SUS 304L Seamless Tubes
- End Protection: Plastic Caps
- Delivery Condition: Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
- Inspection & Test Reports: Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive & Non-Destructive Test Reports
- Grades Supplied: ASTM A269 TP304 Stainless Steel Seamless/Welded Pipes, ASTM A269 TP316L Stainless Steel Seamless/Welded Pipes, SS304 Seamless/Welded Pipes, SS304L Seamless/Welded Pipes, SS316 Seamless/Welded Pipes, SS316L Seamless/Welded Pipes, SS310S Seamless/Welded Pipes, SS317L Seamless/Welded Pipes, 446 Seamless/Welded Pipes
- A269 TP316L Pipe Type: Seamless / ERW / Welded / Fabricated / LSAW Pipes / Seam-welded / Redrawn
ASTM A269 TP316L Tube Suppliers & Exporters
As AISI 304L Tube, ASTM A269 UNS S30403 Tube suppliers and exporters, Nishra Overseas LLP supplies globally, including to UAE, with full material traceability.
- Trade Names & Sizes: ASTM A269 TP316L Tube, ASTM A269 UNS S30403 Tube, Stainless Steel ASTM A269 TP304L Material, 304L Stainless Steel Tube, UNS S30403 Tube
- Size: 6.35 mm OD to 152 mm OD
- Condition: Hard (Y) / Soft (M)
- Dimension: OD × Thk × L (10–219) × (0.5–10) × (1000–15000) mm
- Thickness Range: 0.5 mm – 60 mm
- Grades: AISI 303, 304L, 316L, 316Ti, 321, 403, 410, 416, 420, 420B, 420C, 430F, 431, 17-4PH, Duplex F51 (2205), Duplex F60
- DIN Equivalents: 1.4305, 1.4307, 1.4404, 1.4571, 1.4541, 1.4006, 1.4005, 1.4021, 1.4028, 1.4034, 1.4104, 1.4057, 1.4542, 1.4462, 32205, 1.4122, 1.4435
ASTM A269 TP316L Pipe Manufacturer & Distributor
Nishra Overseas LLP manufactures and supplies AISI 304L Pipe, ASTM A269 UNS S30403 Pipe, as a distributor in Singapore, Saudi Arabia, and other export markets.
- Size: 6.35 mm OD to 152 mm OD
- Origin Standards: American Standard, Russian Standard, Japanese Standard, European Standard
- Delivery: Shortest possible delivery for shutdown, emergency & project rush demands
- Certification: ISO EN 10204 3.1 / 3.1B / 3.2, PED, DNV, TUV
- End Types: Plain End, Beveled End, Threaded
- Reference Manufacturers Sourced From: Sumitomo Metals (Japan), Nippon Steel Corporation (Japan), Kobe Special Tube (Japan), Sanyo Special Steel (Japan), Tubacex Tubos Inoxidables S.A. (Spain), Schoeller Bleckmann (Austria), Seah Steel Corporation (Korea)
ASTM A269 TP316L Seamless Pipe & Tube Supplier
We supply AISI 304L Seamless Pipe/Tube, ASTM A269 UNS S30403 Seamless Pipe/Tube in sizes from 6.35 mm OD to 152 mm OD, referenced by clients including ISC (Japan), ISC (Iran), BHEL (India), Media Air-Conditioning, Samsung (Korea), GNG Co. Ltd (Korea), ZAN (Japan) and GE (USA).
- Specification: ASTM A-213 / ASME SA-213, ASTM A-269 / ASME SA-269, ASTM A312 / ASME SA312, EN10216-5, DIN17458
- Inspection & Testing: Ultrasonic testing, electric non-destructive testing, flaring testing, hydrostatic testing, flattening testing, visual surface inspection, dimensional inspection, tensile properties inspection, chemical elements analysis, bend test, eddy current test, heat treatment, hardness test, I.C. test
- Marking: All Stainless Steel A269 TP316L tubes are marked with Standard, Grade, OD, Thickness, Length, Heat No., or as per customer request
Other Forms We Manufacture, Supply & Export
Nishra Overseas LLP additionally manufactures, supplies and exports the following ASTM A269 / UNS S30403 product forms in size range 6.35 mm OD to 152 mm OD:
- ASTM A269 TP316L Welded Pipe & Tube
- ASTM A269 TP316L Protection Tube
- ASTM A269 TP316L Cold Drawn Seamless Pipe & Tube
- ASTM A269 TP316L Extruded Seamless Pipe & Tube
- ASTM A269 TP316L Round Tube & Square Tube
- ASTM A269 TP316L Coiled Tubing
- ASTM A269 TP316L Rectangular Tube
- ASTM A269 TP316L Tubing Bends
- ASTM A269 TP316L High Temperature Alloy Tubing
- ASTM A269 TP316L Precision Tube & Capillary Tube
- ASTM A269 TP316L Hot Finished Seamless Tubing (HFS)
- ASTM A269 TP316L Cold Drawn Seamless Tubing (CDS)
- ASTM A269 TP316L Electric Resistance Welded (ERW) Tube
- ASTM A269 TP316L Drawn Over Mandrel (DOM) Tube
- ASTM A269 TP316L Heat Exchanger Tube & Finned Tube
Finish: 2B Mill Finish, No.4 Finish, BA Finish, 400 Grit Finish, 550 Grit Finish, 600 Grit Finish
Thickness: 0.5mm, 0.6mm, 0.7mm, 0.8mm, 1.0mm, 1.2mm, 1.5mm, 1.6mm, 2.0mm, 2.5mm, 3.0mm
Material Grades: TP201, TP202, XM-19, TP304, TP304L, TP304H, TP304N, TP304LN, TP309S, TP309H, TP309Cb, TP309HCb, TP310S, TP310H, TP310Cb, TP310HCbN, TP310HCbLN, TP316, TP316L, TP316H, TP316Ti, TP316N, TP316LN, TP317, TP317L, TP317LM, TP317LMN, TP321, TP321H, TP347, TP347H, TP347HFG, TP347LN, TP348, TP348H, XM-15, TP444
Shapes Available: Round Polished Pipes, Square Polished Pipes, Rectangular Polished Pipes, Special Shapes Polished Pipes
Standards for Precision Tube: ASTM A213/ASME SA213, ASTM A269/ASME SA269, A312, A511, A789, A790, A376, EN 10216-5, EN 10297, DIN 17456, DIN 17458, GOST 9941, GOST 9940, JIS G3446, JIS G3447, JIS G3448, JIS G3459, JIS G3463, JIS G3468
Capillary Tube Material Equivalents: TP304/304L/304H, 316/316L, 321/321H, 317/317L, 347/347H, 309S, 310S, S31803, S32205, S32750, S32760, S32304, 904L; Russian grades 08X18H10, 03X18H11, 08X18H10T, 12X18H10T, 08X17H14M2, 03X17H14M2, 10X17H13M2T, 20X23H18; Japanese grades SUS304TP, SUS304LTP, SUS304HTP, SUS316TP, SUS316LTP, SUS316HTP, SUS321TP, SUS321HTP, SUS347TP, SUS347HTP, SUS310STP, SUS317TP, SUS890LTP; EN grades 1.4301, 1.4306, 1.4948, 1.4401, 1.4404, 1.4571, 1.4541, 1.4833, 1.4878, 1.4550, 1.4462, 1.4438, 1.4845
Nominal Dia for Seamless Pipe: 1/2" to 32" NB, Schedules 5S, 10S, 40S, 80S, 10, 20, 30…120, 140, 160, XXS, as per ANSI B36.19 and ANSI B36.10
Tubing Size Range: OD 1/4" (6.25mm) to 8" (203mm), WT 0.02" (0.5mm) to 0.5" (12mm)
Referenced ASTM/ASME Standards: A213, A269, B163, B167, B668, A632, A789, A790; SA213, SB163, SB167, SB668, SA789, SA790; NACE MR0175; EN 10216-5; DIN 17458
Testing Equipment: Direct-reading Spectrograph, Hydrostatic Testing Machine, X-ray Detector, Ultrasonic Flaw Detector, Magnetic Particle Detector
Process: Cold Drawn, Cold Rolled, Precision Rolled for Seamless Pipe or Tube
Equipment: Press Machine, Bending Machine, Pushing Machine, Electric Bevelling Machine, Sand-Blasting Machine, etc.
Origin Options Available: West Europe / Japanese / Indian / USA / Korean / American / European
Test Certificates Provided: Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report
ASTM A269 Stainless Steel Tubing Price List
Nishra Overseas LLP is a stockist and supplier of SA269 Gr TP316 tubing in various sizes and schedules — contact us for a free quote and delivery time. Prices below are indicative FOB ranges; contact us for a firm quote based on grade, size, quantity and finish.
|
Product |
FOB Price Range |
|
ASTM A312 TP304/304L Austenitic SS Welded Pipe / ASTM A269-10 Duplex Steel Pipes |
US $1500–6000 / Ton |
|
ASTM A312 TP304L 3" Sch40 Seamless Water Line Pipe |
US $2500–6000 / Ton |
|
ASTM A312 TP316L SS Welded Pipe (304/304L/316/316L/316H/321/309/310S) |
US $6–12 / Kilogram |
|
ASTM A312 TP321 SS Seamless Pipe |
US $1000–6000 / Ton |
|
ASME B36.19M Seamless SS A312 TP304/304L/316/316L/31803 Pipes |
US $1–10 / Piece |
|
ASTM A312 TP321H Welded SS Pipe |
US $700–1600 / Ton |
|
ASTM A312 TP347H SS Seamless Pipe (1.4mm WT) |
US $1000–3000 / Ton |
|
ASTM A312 TP304L Seamless Pipe for Power Plant |
US $580–650 / Ton |
|
TP304L ASTM A312 Cold Drawn Seamless Heat Exchanger Tubes/Pipes |
US $1100–1600 / Ton |
|
ASTM A312 TP304/316L Pipe for Oil & Gas |
US $300–550 / Ton |
|
TP304L ASTM A312 Wiredrawing Seamless Heat Exchanger Tubes/Pipes |
US $500–1100 / Ton |
ASTM A269 Stainless Steel Tubing Composition and Properties
Chemical Composition % (Max)
|
Grade |
C |
Mn |
P |
S |
Si |
Cr |
Ni |
Mo |
N |
Nb |
Ti |
|
TP304 |
0.08 |
2.00 |
0.045 |
0.030 |
1.00 |
18.0–20.0 |
8.0–11.0 |
– |
– |
– |
– |
|
TP304H |
0.04–0.10 |
2.00 |
0.045 |
0.030 |
1.00 |
18.0–20.0 |
8.0–11.0 |
– |
– |
– |
– |
|
TP304L |
0.035 |
2.00 |
0.045 |
0.030 |
1.00 |
18.0–20.0 |
8.0–13.0 |
– |
– |
– |
– |
|
TP310S |
0.08 |
2.00 |
0.045 |
0.030 |
1.00 |
24.0–26.0 |
19.0–22.0 |
0.75 |
– |
– |
– |
|
TP316 |
0.08 |
2.00 |
0.045 |
0.030 |
1.00 |
16.0–18.0 |
11.0–14.0 |
2.00–3.00 |
– |
– |
– |
|
TP316L |
0.035 |
2.00 |
0.045 |
0.030 |
1.00 |
16.0–18.0 |
10.0–14.0 |
2.00–3.00 |
– |
– |
– |
|
TP316H |
0.04–0.10 |
2.00 |
0.045 |
0.030 |
1.00 |
16.0–18.0 |
11.0–14.0 |
2.00–3.00 |
– |
– |
– |
|
TP316Ti |
0.08 |
2.00 |
0.045 |
0.030 |
0.75 |
16.0–18.0 |
10.0–14.0 |
2.00–3.00 |
0.10 |
– |
5×(C+N)–0.70 |
|
TP321 |
0.08 |
2.00 |
0.045 |
0.030 |
1.00 |
17.0–19.0 |
9.0–12.0 |
– |
0.10 |
– |
5C–0.70 |
|
TP321H |
0.04–0.10 |
2.00 |
0.045 |
0.030 |
1.00 |
17.0–19.0 |
9.0–12.0 |
– |
– |
– |
4C–0.60 |
|
TP347 |
0.08 |
2.00 |
0.045 |
0.030 |
1.00 |
17.0–19.0 |
9.0–13.0 |
– |
– |
10×C–1.00 |
– |
|
TP347H |
0.04–0.10 |
2.00 |
0.045 |
0.030 |
1.00 |
17.0–19.0 |
9.0–13.0 |
– |
– |
8×C–1.00 |
– |
Mechanical Properties
|
Grade |
Heat Treatment |
Min. Temp °F (°C) |
Tensile Strength Ksi (MPa), Min |
Yield Strength Ksi (MPa), Min |
Elongation %, Min |
|
TP304 |
Solution |
1900 (1040) |
75 (515) |
30 (205) |
35 |
|
TP304L |
Solution |
1900 (1040) |
70 (485) |
25 (170) |
35 |
|
TP304H |
Solution |
1900 (1040) |
75 (515) |
30 (205) |
35 |
|
TP310S |
Solution |
1900 (1040) |
75 (515) |
30 (205) |
35 |
|
TP316 |
Solution |
1900 (1040) |
75 (515) |
30 (205) |
35 |
|
TP316L |
Solution |
1900 (1040) |
70 (485) |
25 (170) |
35 |
|
TP316H |
Solution |
1900 (1040) |
75 (515) |
30 (205) |
35 |
|
TP316Ti |
Solution |
1900 (1040) |
75 (515) |
30 (205) |
35 |
|
TP321 |
Solution |
1900 (1040) |
75 (515) |
30 (205) |
35 |
|
TP321H |
Solution |
Cold: 2000 (1100), Hot: 1925 (1050) |
75 (515) |
30 (205) |
35 |
|
TP347 |
Solution |
1900 (1040) |
75 (515) |
30 (205) |
35 |
|
TP347H |
Solution |
Cold: 2000 (1100), Hot: 1925 (1050) |
75 (515) |
30 (205) |
– |
ASTM A269 Stainless Steel Tubing Pressure Rating
Why pay extra? Get A269 316L Tubing in the exact length you need and save on cost — contact Nishra Overseas LLP now!
Allowable pressure (psi) by OD and wall thickness (mm/inch):
|
OD (mm) |
OD (in) |
0.50mm (.020") |
0.75mm (.030") |
1.0mm (.039") |
1.2mm (.047") |
1.5mm (.059") |
2mm (.079") |
2.5mm (.098") |
3mm (.118") |
4mm (.157") |
5mm (.197") |
6mm (.236") |
8mm (.315") |
|
3.0 |
0.1181 |
6538 |
10625 |
15455 |
– |
– |
– |
– |
– |
– |
– |
– |
– |
|
3.5 |
0.1378 |
5484 |
8793 |
12593 |
– |
22174 |
– |
– |
– |
– |
– |
– |
– |
|
4.0 |
0.1575 |
4722 |
7500 |
10625 |
– |
18214 |
– |
– |
– |
– |
– |
– |
– |
|
6.0 |
0.2362 |
– |
– |
6538 |
8095 |
10625 |
– |
– |
– |
– |
– |
– |
– |
|
8.0 |
0.3150 |
– |
– |
4722 |
5795 |
7500 |
10625 |
– |
– |
– |
– |
– |
– |
|
10.0 |
0.3937 |
– |
– |
3696 |
4513 |
5795 |
8095 |
– |
– |
– |
– |
– |
– |
|
12.0 |
0.4724 |
– |
– |
3214 |
3913 |
5000 |
6923 |
– |
– |
– |
– |
– |
– |
|
14.0 |
0.5512 |
– |
– |
2727 |
3313 |
4219 |
5806 |
– |
– |
– |
– |
– |
– |
|
15.0 |
0.5906 |
– |
– |
2535 |
3077 |
3913 |
5373 |
– |
– |
– |
– |
– |
– |
|
16.0 |
0.6299 |
– |
– |
2368 |
2872 |
3649 |
5000 |
6429 |
7941 |
– |
– |
– |
– |
|
18.0 |
0.7087 |
– |
– |
2093 |
2535 |
3214 |
4390 |
5625 |
6923 |
– |
– |
– |
– |
|
20.0 |
0.7874 |
– |
– |
1875 |
2269 |
2872 |
3913 |
5000 |
6136 |
8571 |
– |
– |
– |
|
22.0 |
0.8661 |
– |
– |
1698 |
2053 |
2596 |
3529 |
4500 |
5510 |
7660 |
– |
– |
– |
|
25.0 |
0.9843 |
– |
– |
1488 |
1797 |
2269 |
3077 |
3913 |
4779 |
6606 |
– |
– |
– |
|
28.0 |
1.1024 |
– |
– |
1324 |
1598 |
2015 |
2727 |
3462 |
4219 |
5806 |
– |
– |
– |
|
30.0 |
1.1811 |
– |
– |
1233 |
1488 |
1875 |
2535 |
3214 |
3913 |
5373 |
6923 |
8571 |
12203 |
|
35.0 |
1.3780 |
– |
– |
1053 |
1269 |
1598 |
2156 |
2727 |
3313 |
4528 |
5806 |
7152 |
10070 |
|
38.0 |
1.4961 |
– |
– |
968 |
1166 |
1467 |
1978 |
2500 |
3034 |
4138 |
5294 |
6506 |
9114 |
|
42.0 |
1.6535 |
– |
– |
874 |
1053 |
1324 |
1782 |
2250 |
2727 |
3711 |
4737 |
5806 |
8090 |
|
50.0 |
1.9685 |
– |
– |
732 |
881 |
1107 |
1488 |
1875 |
2269 |
3077 |
3913 |
4779 |
6606 |
ASTM A269 SS Tubing Dimensions
Weight in Kgs per bundle, by wall thickness (mm):
|
OD (in) |
OD (mm) |
Qty/Bundle |
0.6 |
0.7 |
0.8 |
0.9 |
1.0 |
1.2 |
1.5 |
2.0 |
3.0 |
4.0 |
5.0 |
6.0 |
|
3/8" |
9.5 |
100 |
0.81 |
0.94 |
1.06 |
1.18 |
1.29 |
1.51 |
1.82 |
– |
– |
– |
– |
– |
|
1/2" |
12.7 |
100 |
1.10 |
1.28 |
1.45 |
1.61 |
1.78 |
2.10 |
2.55 |
– |
– |
– |
– |
– |
|
5/8" |
15.9 |
100 |
1.39 |
1.62 |
1.84 |
2.05 |
2.26 |
2.68 |
3.28 |
– |
– |
– |
– |
– |
|
3/4" |
19.1 |
100 |
1.69 |
1.96 |
2.22 |
2.49 |
2.75 |
3.26 |
4.01 |
– |
– |
– |
– |
– |
|
7/8" |
22.2 |
100 |
1.97 |
2.29 |
2.60 |
2.91 |
3.22 |
3.83 |
4.72 |
– |
– |
– |
– |
– |
|
1" |
25.4 |
100 |
2.26 |
2.63 |
2.99 |
3.35 |
3.71 |
4.41 |
5.45 |
– |
– |
– |
– |
– |
|
1 1/8" |
28.6 |
50 |
2.55 |
2.97 |
3.38 |
3.79 |
4.19 |
5.00 |
6.18 |
– |
– |
– |
– |
– |
|
1 1/4" |
31.8 |
50 |
2.84 |
3.31 |
3.77 |
4.23 |
4.68 |
5.58 |
6.91 |
– |
– |
– |
– |
– |
|
1 1/2" |
38.1 |
50 |
3.42 |
3.98 |
4.53 |
5.09 |
5.64 |
6.73 |
8.34 |
– |
– |
– |
– |
– |
|
1 5/8" |
41.3 |
50 |
3.71 |
4.32 |
4.92 |
5.52 |
6.12 |
7.31 |
9.07 |
– |
– |
– |
– |
– |
|
1 3/4" |
44.5 |
50 |
4.00 |
4.66 |
5.31 |
5.96 |
6.61 |
7.90 |
9.80 |
– |
– |
– |
– |
– |
|
2" |
50.8 |
10 |
– |
– |
6.08 |
6.82 |
7.57 |
9.04 |
11.24 |
14.83 |
21.79 |
– |
– |
– |
|
2 1/2" |
63.5 |
10 |
– |
– |
7.62 |
8.56 |
9.50 |
11.36 |
14.13 |
18.69 |
27.58 |
– |
– |
– |
|
3" |
76.2 |
10 |
– |
– |
9.17 |
10.30 |
11.43 |
13.68 |
17.03 |
22.55 |
33.37 |
43.88 |
– |
– |
|
3 1/2" |
88.9 |
10 |
– |
– |
10.71 |
12.03 |
13.36 |
15.99 |
19.92 |
26.41 |
39.16 |
51.60 |
– |
– |
|
4" |
101.6 |
10 |
– |
– |
– |
– |
– |
18.31 |
22.82 |
30.27 |
44.95 |
59.32 |
73.39 |
87.16 |
|
5" |
127 |
10 |
– |
– |
– |
– |
– |
– |
– |
– |
– |
– |
– |
– |
|
6" |
152.4 |
10 |
– |
– |
– |
– |
– |
– |
– |
– |
– |
– |
– |
– |
Why Choose Nishra Overseas LLP as Your ASTM A269 Tube Partner
- Trusted ASTM A269 Stainless Steel Tube Manufacturer in India, ISO 9001:2015 certified, based in Mumbai
- Reliable ASTM A269 Tube Supplier in India, holding wide stock of SA269 Gr TP316 tubing in various sizes and schedules
- Established ASTM A269 Tube Exporter in India, shipping to 50+ countries including Malaysia, Singapore, Saudi Arabia and UAE
- Full grade range — TP304, TP304L, TP304H, TP316, TP316L, TP316Ti, TP321, TP321H, TP347, TP347H, TP310S
- Cut-to-size lengths supplied at no extra cost, saving customers on freight and material wastage
- Ideal for hydraulic systems, textile, marine, chemical, food, beverage and petrochemical processing applications
- Every consignment backed by Mill Test Certificates (EN 10204 3.1/3.1B), third-party inspection and NABL-approved lab reports
Request a Quote
Looking for a reliable ASTM A269 Stainless Steel Tube Manufacturer, Supplier or Exporter in India? Contact Nishra Overseas LLP today for the latest price list, product datasheets, and free samples.
